Wechai 260hp diesel off-road truck Chassis–Dongfeng 4*4 flathead Fire truck Chassis–Custom Chassis Export Manufacturer
Product Description
4×4 Dongfeng truck chassis (4×2 drive available as an option); the 4×4 configuration is suitable for use on rough terrain and offers superior off-road performance, while the 4×2 configuration is ideal for urban roads, providing a lightweight and fuel-efficient option. Custom modifications and upgrades can be made according to customer requirements.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | WP10.260E32 |
| Gearbox | Mechanical Manual Ten speed |
| Cab | Flathead row half |
| Axle | Max. Load 5Tons/13Tons (Front/Rear) |
| Tyre | 11.00R20 (6+1) |
| Circuit | 24V circuit system |
| Other | Buckets, oil drums, fire extinguishers, vehicle tools, tarpaulin poles |
| Performance Parameter | |||
| Chassis Dimension(mm) | 7850 × 2400 × 2920(Length×Width×Height) | ||
| Superstructure length(mm) | ≥5300 | ||
| Total Mass(kg) | 18000 | Curb Weight(kg) | 6090 |
| Wheelbase（mm） | 3950 | Axlebase(mm) | 1980/1810 |
| Approach Angle (°) | 28 | Departure Angle (°) | 16 |
| Ground Clearance(mm) | 300 | Fording depth (mm) | 600 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 320 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
