Dongfeng 4WD Armoured Vehicle Chassis–Allison Automatic Left-drive Class III Chassis–Class III Chassis Agent Export Manufacturer
Product Description
The 4*4 off-road vehicle class III chassis is a chassis model designed one-to-one by our company according to the customer’s requirements. After multi-faceted design, testing and perfecting, the chassis’ passability reaches the customer’s indexes. The chassis cab and top load are perfected by customers themselves, and will be exported to Africa for use.
Product Parameter
| Basic Configuration | |
| Engine | Cummins ISDe200 41 |
| Gearbox | Allison Automatic |
| Transmission | High-low |
| Axle | Max. Load 5Tons/5Tons/5Tons (Front/Middle/Rear) |
| Tyre | 305/18R18(4+1) |
| Frame | Double-layer welded closure |
| Suspension | Front: Independent suspension/Rear: Leaf spring |
| Other | Front-mounted electric winch, central tire inflation/deflation system, air conditioning, tire inner support, anti-skid system, anti-collision lights, airdrop capability |
| Performance Parameter | |||
| Type III chassis dimensions | 4950× 2300× 1500(Length×Width×Height) | ||
| Axlebase(mm) | 1790/1830 | Wheelbase(mm) | 3300 |
| Max. Power(kW/rpm) | 155 | Displacement(L) | 6.7 |
| Curb weight(kg) | 2860 | G.V.W(kg) | 6000 |
| Max. torque(N.m) | 800 | Departure Angle (°) | 40 |
| Approach Angle (°) | 41 | Overrun height (mm) | 540 |
| Max. gradient(％) | 60 | Fording Depth(mm) | 720 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
