Dongfeng 260 HP Rear Dual Tire Special Off-road Chassis–Dongfeng Flathead 4*2 Chassis–Off-road Truck Export Manufacturer
Product Description
4*2 Dongfeng light truck chassis, can be converted into a special type of truck for municipal sanitation, road rescue, storage and transportation and other fields. Whether it’s a city road or a remote mountain road, with its excellent off-road performance, unparalleled driving experience.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×2 |
| Engine | Yuchai 260hp |
| Gearbox | Mechanical Manual ten speed |
| Cab | Flathead one and a half row |
| Axle | Max. Load 6.5Tons/13Tons (Front/Rear) |
| Tyre | 11.00R20(6 + 1) |
| Suspension | Steel plate springs 9/8+9 |
| Performance Parameter | |||
| Chassis Dimension(mm) | 9080× 2580 × 2970(Length×Width×Height) | ||
| Modification Dimension(mm) | ≥6490 | ||
| Total Mass(kg) | 19500 | No. of Members | 3 |
| Max. Power(kW/rpm) | 191 | Axlebase(mm) | 2020/1850 |
| Wheelbase(mm) | 5100 | Displacement(L) | 6.23 |
| Approach Angle (°) | 13 | Departure Angle (°) | 16 |
| Fording Depth(mm) | 470 | Ground Clearance(mm) | 330 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 160 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
