EQ2050E Long-head Double-row Hard-top Dongfeng Off-road Vehicle

Short Description:

Product Detail

Product Tags

Product Description

Basic configuration uses (divided) teams, patrol and other mandate modified various types of machines, surveying, electronic information, etc. Special vehicles can be transported by Ir -76, transportation eight and other air transportation, airdrops, railway ship transportation.

Product Parameter

Basic Configuration
Drive Mode 4×4
Engine Cummins EQB150-20
Gearbox Mechanical Manual five speed
Transfer case High-low speed
Cab Two seats
Axle Max. Load 1.9Tons/2.8Tons (Front/Rear)
Tyre 37 × 12.5R16.5LT
Performance Parameter
Overall Dimension(mm) 4717 × 2210 × 1930(Length×Width×Height)
Total Mass(kg) 5000 Load Weight(kg) 1750
Max. Power(kW/rpm) 110 Tank Capacity(L) 76+39
Wheelbase(mm) 3300 Displacement(L) 5.9
Max. gradeability (°) 60 Fuel consumption per 100km(L) 20
Ground Clearance(mm) ≤410 Fording depth (mm) 750/1200
Max. Speed(km/h) 110 Adaptive Altitude(m) 500

This parameter is for reference only. The margin of error is plus or minus three percentage points.
