Four wheel drive flat head engineering rescue vehicle
Product Description
Fourr wheel drive Off-road engineering vehicles use Dongfeng Classic off-road chassis, off-road performance, can travel in harsh road, suitable for rescue disaster relief, road construction, material transportation, etc.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Axle | Max. Load 2.8Tons/4.2Tons (Front/Rear) |
| Tyre | 11.00R18 (4 + 1) |
| Electrical appliance |
24V circuit system |
| Other | Optional winch, heater, air conditioning, water dispenser, reversing image |
| Performance Parameter | |||
| Overall Dimension(mm) | 6935 × 2180 × 2780(Length×Width×Height) | ||
| Cargo size(mm) | 2580 × 2100 × 600 | ||
| Total Mass(kg) | 7000 | Frront/Rear Suspension(mm) | 900/1000 |
| Max. Power(kW/rpm) | 125 | Max. Torque(N.m) | 560 |
| Wheelbase(mm) | 3730 | Displacement(L) | 5.9 |
| Approach Angle (°) | 29 | Departure Angle (°) | 17 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 100 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
