Four wheel drive Off-road engineering rescue vehicle
Product Description
This vehicle can be used to be as engineering rescue vehicle .
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B140 33 |
| Gearbox | Five speed |
| Axle | Max. Load 2.7Tons/3.5Tons (Front/Rear) |
| Tyre | 7.50R16 (6 + 1) |
| Electric appliance |
24V circuit sysytem |
| Performance Parameter | |||
| Overall Dimension(mm) | 5990 × 2300 × 2980(Length×Width×Height) | ||
| Cargo size(mm) | 1800 × 2180 × 570 | ||
| Body structure | Half-loaded structure | ||
| Rated passengers (person) | 6~9 | ||
| Max. Power(kW/rpm) | 140 | ||
| Total Mass(kg) | 6300 | Curb Weight(kg) | 4600 |
| Wheelbase(mm) | 3300 | Displacement(L) | 3.9 |
| Approach Angle (°) | 29 | Departure Angle (°) | 23 |
| AC System |
Anti-cycle wind, large cooling capacity, 8KW | ||
This parameter is for reference only. The margin of error is plus or minus three percentage points.
