Dongfeng Four wheel drive long head EQ1093 off-road chassis
Product Description
EQ1093 Four wheel drive Off-road chassis 4 × 4, advantage: suitable for natural conditions and harsh mountains, desert areas, can easily deal with bad pavements; this Four wheel drive chassis can be modified into a variety of Special vehicles, widely used in large fields, oilfield, mining, electricity, water conservancy, rescue, material transportation and other fields; car portable load, effectively improves the utilization of equipment.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 3Tons/8.5Tons (Front/Rear) |
| Tyre | 9.00-20 (6 + 1) |
| Electrical appliance | 24V circuit system |
| Other | Traction hook (Front / rear), ahead of the winch, traction 44100N (optional) |
| Performance Parameter | |||
| Overall Dimension(mm) | 6605 × 2364 × 2370(Length×Width×Height) | ||
| Modification size(mm) | 3850 | ||
| Total Mass(kg) | 7910 | Curb Weight(kg) | 4550 |
| Max. Power(kW/rpm) | 125 | Max. Torque(N.m) | 560 |
| Wheelbase(mm) | 3950 | Displacement(L) | 5.9 |
| Approach Angle (°) | 42 | Departure Angle (°) | 26 |
| Ground Clearance(mm) | 305 | Max. Gradeability (%) | 60 |
| Max. Speed(km/h) | 90 | T100 km fuel consumption(L) | 24 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
