Dongfeng Four-Drive Off-road Truck Chassis
Product Description
Dongfeng Four-Drive Off-road Truck Chassis
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Three seats, D912 flat head Half-cab |
| Axle | Max. Load 3.5Tons/3.5Tons (Front/Rear) |
| Tyre | 11R18 (4 + 1) |
| Electrical Appliance |
24V Circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 6395 × 2250 × 2640(Length×Width×Height) | ||
| Modification size(mm) | 4435 | ||
| Total Mass(kg) | 5100 | ||
| Max. Power(kW/rpm) | 125 | Max. Torque(N.m) | 640 |
| Wheelbase(mm) | 3700 | Displacement(L) | 5.9 |
| Approach Angle (°) | 23 | Departure Angle (°) | 21 |
| Ground Clearance(mm) | 285 | Tank Capacity(L) | 120 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
