Dongfeng EQ5120 Truck Chassis
Product Description
This vehicle is used in Dongfeng EQ5120 Truck Chassis.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins ISB190 40 |
| Gearbox | Mechanical six speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 3.6Tons/3.6Tons/3.6T (Front/Middle/Rear) |
| Tyre | 12.5R20 (6 + 1) |
| Electrical appliance | 24V circuit system |
| Other | Hydraulic steering power, exhaust braking |
| Performance Parameter | |||
| Chassis Model |
EQ1120GSZ3GJ2 | ||
| Total Mass(kg) | 10800 | Curb Weight(kg) | 7700 |
| Max. Power(kW/rpm) | 140 | Max. Torque(N.m) | 640 |
| Wheelbase(mm) | 3475 + 1250 | Displacement(L) | 5.9 |
| Approach Angle (°) | 30 | Departure Angle (°) | 22 |
| Ground Clearance(mm) | 310 | Fording depth (mm) | 505 |
| Max. Speed(km/h) | 87 | Tank Capacity(L) | 300 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
