Dongfeng 4*4 EQ2140B Chassis New Model 4WD Off-road Chassis
Product Description
Dongfeng 4*4 EQ2140B Chassis.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | D6.7 |
| Gearbox | Mechanical Manual Eight speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 6.5Tons/7.5Tons (Front/Rear) |
| Tyre | 12.5R20 (4 + 1) |
| Electrical Appliance | 24V Circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | L 7600×W 2430×H 3150 | ||
| Curb Weight(kg) | 5800 | ||
| Max. Power(kW/rpm) | 140 | Max. Torque(N.m) | 640 |
| Wheelbase(mm) | 3950 | Displacement(L) | 5.9 |
| Approach Angle (°) | 35 | Departure Angle (°) | 22 |
| Ground Clearance(mm) | 328 | Grade Ability(°) | 30 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 280 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
